Alarm Cable

Alarm Cable

Conductor: Cooper Conductor of Class 1/2 (Solid)
Insulation: Fire resistant PVC
Insulation Color: Colors
Wrap: Fire resistant tape
Jacket: Fire resistant PVC
Temperature Range:-10 —- +70℃
Nominal Voltage: 300/500V , 450/750 V

Category Control Cable Tag fire alarm cable,low smoke cable ,security alarm cable,fire resistance cables,cables

1. Introduction of safe Aluminium cable

Alarm Cable is suitable for alarm systems. The insulation and outer sheath provided here is fire resistant PVC. Bare copper, solid wire conductor.Welcome to inquiry.

2. Parameter (Specification) of safe Aluminium cable

Description	Alarm Cable
Conductor:	Solid Copper Conductor of Class 1/2 (Solid)
Insulation:	Fire resistant PVC Compound
Insulation Color	Red, Blue, Yellow/Green or as requested
Wrap	Fire resistant tape
Sheath	Fire resistant PVC Compound
Sheath Color	Black, Grey or as requested
Rated Temperature	70℃
Rated voltage:	300/500V
Test Voltage:	2500 V
Minimal Bending Radius:	12D

Technical Data

Cores x section area mm2	Conductor Specification mm	O.D. mm	Cable weight kg/km
2 X 0,28	0.60./0..0.6	4.4	30.222
4 X 0,28	0.60	5.1	39.5
6 X 0,28	0.60	5.4	47.2
8 X 0,28	0.60	6.2	56.7
10 X 0,28	0.60	6.5	66.1
12 X 0,28	0.60	6.9	75.7
2 X 1,5	1.38	7.7	53.7
4 X 1,5	1.38	8.4	68.6
6 X 1,5	1.38	10.2	112.2
8 X 1,5	1.38	11.6	141.6
10 X 1,5	1.38	13.2	162.4
12 X 1,5	1.38	13.8	195.9

3. Feature of safe Aluminium cable

1) Easy stripping and cutting
2)RoHS2.0 & Reach compliant
3) Can add resistance to fire

4. Detail of safe Aluminium cable

1) Conditionally resistant to fire
2) Standard sizes and custom colors available upon request (black, red, yellow, orange,green, white…).
3) Used as control cables
4) Brand: Anyte

5 Packaging & Delivery

1) Packaging Details:

There’s a roll, reel, drum, pallet, and wooden case for your choice.

2) Port: Main SHANGHAI, NINGBO, and other ports are ok too.

Delivery: By Sea, By Air, By express.

6 FAQ:

Q: How do you deliver your goods to me? How long will it take?

A: We can ship goods by DHL, TNT, UPS, Air freight, Ocean freight, and Truck freight. We help our customers to choose the best shipment way according to the actual situation.

What is your lead time for bulk goods?

A: Honestly, it depends on order quantity and cable material. Normal lead time is around 2-3 weeks.
